Product Description:
An Automatic Blow Moulding Machine is a versatile and essential
piece of equipment utilized in the production of plastic
containers, bottles, cans, and various other products. These
machines have become a go-to choice for manufacturers due to their
speed, efficiency, and high degree of accuracy.
The Blow Moulding Machine processes preheated plastic pellets by
blowing and molding them into the desired products based on
pre-designed molds. This automated process allows the machines to
produce high-quality products with consistent shape and size.
Furthermore, the machines can produce the products with a lower
likelihood of defects, which ultimately saves time and resources.
The Automatic Blow Moulding Machine is a crucial development in the
world of plastic production, enabling manufacturers to increase
productivity and reduce costs while maintaining high standards of
quality. By streamlining the production process, businesses can
compete more effectively in the marketplace and ensure that their
products meet the demands of their customers.
Features:
- Product Name: Automatic Blow Moulding Machine
- Color: Customized
- Warranty Time: 1 Year
- Clamping System: Toggle Type Clamping System
- Blow Moulding Type: Extrusion Blow Moulding
- Mold Weight: Max. 5000 Kg
- 4 cavity blow moulding machine
- PET blow moulding machine
- Blow molding machine
Technical Parameters:
| MP70FS |
| Single station blow molder with horizontal linear mould shuttle |
| Length: | 3600mm | | |
| Width: | 2200mm | | |
| Height | 2360mm | | |
| | | | |
| Key Data | | MP70FS |  |
| | mm |
| Linear mould stroke | A | 520 |
| Mould Width | B | 500 |
| Mould Length | C | 400 |
| Mould Thickness | D | 250 |
| Opening Stroke | E | 350 |
| | |
| Platen daylight | D+E | 600 |
| Clamping Force | | 75kN | | |
| Dry Cycle | | 7 sec. | | |
| Centre Distance | 1x2 fold | 160 | | |
| 1x3 fold | 120 | | |
| 1x4 fold | 100 | | |
| 1x6 fold | 60 | | |
| | | | |
| Extruder | | φ70 | φ75 | φ80 |
| Screw Speed | r/min | 0~65 | 0~65 | 0~65 |
| Screw Diameter | mm | 70 | 75 | 80 |
| Screw L/D Ratio | L/D | 24 | 24 | 24 |
| | | | |
| Energy Requirements | | | | |
| Extruder Inverter Power | kW | 18.5 | 22 | 30 |
| Extruder Moter Power | kW | 18.5 | 22 | 30 |
| Srew Heating Power | kW | 12.7 | 14.4 | 15.85 |
| Fan Power | kW | 0.14X2 | 0.14X2 | 0.14X2 |
| Oil pump Motor Power | kW | 15 | 15 | 15 |
| Total Power of Machine | kW | 49.14 | 54.34 | 63.79 |
| Air Requirement approx | m3/min | 1.2 | 1.2 | 1.2 |
| Air Working Pressure | Mpa | 0.6-0.8 | 0.6-0.8 | 0.6-0.8 |
| | | | |
| Cooling Requirements | | | | |
| Consumption Cooling Water | L/min | 40 | 40 | 40
|
Applications:
The automatic blow moulding machine is suitable for a wide range of
product application occasions and scenarios. It is perfect for
producing plastic bottles, jars, containers, and other similar
products. Industries such as food and beverage, cosmetics,
pharmaceuticals, and household products can benefit from this
machine. The MP70FS-4 model has a maximum container capacity of
10L, making it suitable for producing larger products.
The blow molding machine is designed for ease of use, with a new
door design that makes it easy to maintain and operate. The machine
has a Schneider contactor and comes with a 1-year warranty. The
color of the machine can be customized to match the customer's
preferences. The packaging details are standard export package, and
the delivery time is 25-35 work days.
The plastic blow moulding machine is compatible with both L/C and
T/T payment methods, making it easy for customers to make their
purchases. The price of the machine is negotiable, making it
affordable for businesses of all sizes. With its high efficiency
and quality output, the MP70FS-4 New door design automatic blow
moulding machine is a great investment for any business looking to
start or expand their plastic product production.
